● 適用于所有拉伸、彎曲、成形、沖裁落料、翻邊等各種工藝。
Sheet metal stretching, blanking, stamping and all stretch flange forming process, but also for correction, press-fit technology, widely used in the following industries:
● 計算機優化結構設計,四柱式結構簡單、經濟、實用;框架式結構剛性好、精度高、抗偏載能力強。
● 液壓控制采用插裝式集成系統,動作可靠,使用壽命長,液壓沖擊小,減少了連接管路與泄漏點。
● 采用PLC控制的電氣系統,結構緊湊、工作靈敏、可靠、柔性好。
● 通過操作面板選擇,不僅可實現定程,定壓兩種成形工藝,而且可實現有墊、無墊、頂出三種工藝工作循環。
另外可以選配前后知道就行輥道和機械手。
Application:
Sheet metal stretching, blanking, stamping and all stretch flange forming process, but also for correction, press-fit technology, widely used in the following industries:
Auto parts: body panels, brake, fuel tank, chassis, axle housing, bumper
Kitchen appliances: sink, a pot, stainless steel appliances, and other containers.
Other: tractors, motorcycles, aerospace, aviation, chemicals, instruments, machine tools
Advantages:
1.Simple 4-column structure and reliable operating system
2.With movable working table
3.Easy and practical to change die
4.Uses PLC control to make sure that operating sensitive and reliable
5.Mechanical, electrical and hydraulic integration
Product Description:
The hydraulic press use optimized design of computer with international advanced level. The frame structure, rigid, high precision, strong resistance to side load capacity. Corners directions with guide,high guiding precision New fuel tank sealing components, high reliability, long life.
The hydraulic press have fast working speed,improve the production efficiency. The working pressure and stroke can be adjusted according to process requirements, easy to operate.
Our hydraulic have low noise which can replace the mechanical press.
Using non-contact displacement sensor or switch, improve the reliability and accuracy of stroke control.
Mechanical, electrical, hydraulic integration of safety devices, security is superior.
TECHNICAL SPECIFICATIONS:
Item 名稱 | Unit單位 | ZBJ-100T | ZBJ-200T | ZBJ-315T | ZBJ-400T | ZBJ-500T | ZBJ-630T | ZBJ-800T | ZBJ-1000T | |
Nominal force 公稱力 | KN | 1000 | 2000 | 3150 | 4000 | 5000 | 6300 | 8000 | 10000 | |
Return force 回程力 | KN | 160 | 240 | 600 | 500 | 900 | 850 | 1000 | 1350 | |
Slide stroke | KN | 510 | 710 | 800 | 800 | 900 | 900 | 1000 | 1000 | |
Open height打開高度 | mm | 800 | 1120 | 1250 | 1250 | 1500 | 1500 | 1800 | 1800 | |
Hydraulic cushion nominal force拉伸力 | kn | 400 | 630 | 1250 | 1250 | 2000 | 1250*2 | 1600*2 | 2000*2 | |
Hydraulic cushion return force拉伸滑塊行程 | kn | 147 | 250 | 360 | 360 | 780 | 360*2 | 600*2 | 580*2 | |
Hydraulic cushion stroke 壓邊滑塊行程 | mm | 200 | 250 | 300 | 300 | 350 | 350 | 400 | 400 | |
Slide speed 拉伸滑塊速度 | Down 下降 | mm / S | 100 | 150 | 100 | 130 | 120 | 130 | 150 | 130 |
Work 工作 | mm / S | 7-15 | 5-12 | 5-12 | 4-10 | 7-15 | 5-12 | 5-12 | 5-12 | |
Return 回程 | mm / S | 85 | 95 | 60 | 70 | 80 | 85 | 95 | 85 | |
Hydraulic cushion speed 壓邊滑塊速度 | Up 上 | mm / S | 35 | 38 | 30 | 30 | 37 | 30 | 30 | 30 |
Return 回程 | mm / S | 100 | 95 | 100 | 100 | 95 | 105 | 85 | 105 | |
Working table工作臺面尺寸 | L-R 左右 | mm | 690 | 1000 | 1260 | 1250 | 1400 | 1600 | 2200 | 2500 |
Effective size有效工作臺面尺寸 | Front-back前后 | mm | 630 | 940 | 1160 | 1250 | 1400 | 1600 | 1600 | 1800 |
Motor Power 電機功率 | KW | 7.5 | 15 | 22 | 22 | 44 | 44 | 60 | 66 |
